RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
169
Sep 22, 2011
For example, figures 4-1 to 4-6 show block diagr
ams of port 0 for 128-pin pr
oducts when PIOR = 00H.
Figure 4-1. Block Diagram of P00
Internal bus
Output latch
(P00)
Alternate
function
P00/TI00
WR
PU
RD
WR
PORT
PU00
EV
DD
P-ch
PU0
P0
WR
PM
PM0
POM00
POM0
WR
POM
PM00
Selector
P0:
Port register 0
PU0:
Pull-u
p resistor option register 0
PM0:
Port mode register 0
POM0:
Port output mode register 0
RD: Read
sign
al
WR
××
: Write
signal
<R>
