CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
190
Sep 22, 2011
Figure 4-18. Block Di
agram of P32 to P34
P32 to P34
WR
PU
RD
WR
PORT
WR
PM
EV
DD
P-ch
PU3
PM3
P3
PM32 to PM34
PU32 to PU34
Output latch
(P32 to P34)
Selector
Internal bus
P3:
Port register 3
PU3:
Pull-u
p resistor option register 3
PM3:
Port mode register 3
RD: Read
sign
al
WR
××
: Write
signal
