RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
194
Sep 22, 2011
For example, figures 4-20 to 4-26 show block
diagrams of port 4 for 128-pin products when PIOR =
00H.
Figure 4-20. Blo
ck Diagram of P40
P40/TOOL0
RD
WR
PORT
WR
PM
PM4
P4
WR
PU
EV
DD
P-ch
PU4
PM40
PU40
Output latch
(P40)
Selector
Selector
Alternate
function
Alternate
function
Internal bus
P4:
Port register 4
PU4:
Pull-u
p resistor option register 4
PM4:
Port mode register 4
RD: Read
sign
al
WR
××
: Write
signal
<R>
212
214
