RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
238
Sep 22, 2011
Figure 4-54. Block Di
agram of P125 to P127
P125 to P127
WR
PU
RD
WR
PORT
WR
PM
EV
DD
P-ch
PU12
PM12
P12
PM125 to PM127
PU125 to PU127
Output latch
(P125 to P127)
Selector
Internal bus
P12:
Port register 12
PU12:
Pull-up resistor option register 12
PM12:
Port mode regi
ster 12
RD: Read
sign
al
WR
××
: Write
signal
256
