RL78/G13 CHAPTER 5 CLOCK GENERATOR
R01UH0146EJ0100 Rev.1.00 314
Sep 22, 2011
Table 5-3. CPU Clock Transition and SFR Register Setting Examples (2/5)
(4) CPU clock changing from high-speed on-chip oscillator clock (B) to high-speed system clock (C)
(Setting sequence of SFR registers)
CMC Register
Note 1
CSC
Register
CKC
Register
Setting Flag of SFR Register
Status Transition
EXCLK OSCSEL AMPH
OSTS
Register
MSTOP
OSTC Register
MCM0
(B) → (C)
(X1 clock: 1 MHz ≤ fX ≤ 10 MHz)
0 1 0 Note 2 0 Must be checked 1
(B) → (C)
(X1 clock: 10 MHz < fX ≤ 20 MHz)
0 1 1 Note 2 0 Must be checked 1
(B) → (C)
(external main clock)
1 1
×
Note 2 0 Must not be checked 1
Unnecessary if these registers
are already set
Unnecessary if the CPU is operating with
the high-speed system clock
Notes 1. The clock operation mode control register (CMC) can be changed only once after reset release. This
setting is not necessary if it has already been set.
2. Set the oscillation stabilization time as follows.
• Desired the oscillation stabilization time counter status register (OSTC) oscillation stabilization time ≤
Oscillation stabilization time set by the oscillation stabilization time select register (OSTS)
Caution Set the clock after the supply voltage has reached the operable voltage of the clock to be set (see
CHAPTER 29 ELECTRICAL SPECIFICATIONS.
(5) CPU clock changing from high-speed on-chip oscillator clock (B) to subsystem clock (D)
(Setting sequence of SFR registers)
CMC Register
Note
CSC
Register
CKC Register
Setting Flag of SFR Register
Status Transition
EXCLKS OSCSELS XTSTOP
Waiting for
Oscillation
Stabilization
CSS
(B) → (D)
(XT1 clock)
0 1 0 Necessary 1
(B) → (D)
(external sub clock)
1 1 0 Necessary 1
Unnecessary if the CPU is operating
with the subsystem clock
Note The clock operation mode control register (CMC) can be written only once by an 8-bit memory manipulation
instruction after reset release.
Remarks 1. ×: don’t care
2. (A) to (J) in Table 5-3 correspond to (A) to (J) in Figure 5-15.
