RL78/G13 CHAPTER 6 TIMER ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 337
Sep 22, 2011
Figure 6-7. Format of Timer Clock Select register m (TPSm) (1/2)
Address: F01B6H, F01B7H (TPS0), F01F6H, F01F7H (TPS1) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TPSm 0 0
PRS
m31
PRS
m30
0 0
PRS
m21
PRS
m20
PRS
m13
PRS
m12
PRS
m11
PRS
m10
PRS
m03
PRS
m02
PRS
m01
PRS
m00
Selection of operation clock (CKmk)
Note
(k = 0, 1)
PRS
mk3
PRS
mk2
PRS
mk1
PRS
mk0
f
CLK = 2 MHz fCLK = 5 MHz fCLK = 10 MHz fCLK = 20 MHz fCLK = 32 MHz
0 0 0 0 fCLK 2 MHz 5 MHz 10 MHz 20 MHz 32 MHz
0 0 0 1 fCLK/2 1 MHz 2.5 MHz 5 MHz 10 MHz 16 MHz
0 0 1 0 fCLK/2
2
500 kHz 1.25 MHz 2.5 MHz 5 MHz 8 MHz
0 0 1 1 fCLK/2
3
250 kHz 625 kHz 1.25 MHz 2.5 MHz 4 MHz
0 1 0 0 fCLK/2
4
125 kHz 312.5 kHz 625 kHz 1.25 MHz 2 MHz
0 1 0 1 fCLK/2
5
62.5 kHz 156.2 kHz 312.5 kHz 625 kHz 1 MHz
0 1 1 0 fCLK/2
6
31.25 kHz 78.1 kHz 156.2 kHz 312.5 kHz 500 kHz
0 1 1 1 fCLK/2
7
15.62 kHz 39.1 kHz 78.1 kHz 156.2 kHz 250 kHz
1 0 0 0 fCLK/2
8
7.81 kHz 19.5 kHz 39.1 kHz 78.1 kHz 125 kHz
1 0 0 1 fCLK/2
9
3.91 kHz 9.76 kHz 19.5 kHz 39.1 kHz 62.5 kHz
1 0 1 0 fCLK/2
10
1.95 kHz 4.88 kHz 9.76 kHz 19.5 kHz 31.25 kHz
1 0 1 1 fCLK/2
11
976 Hz 2.44 kHz 4.88 kHz 9.76 kHz 15.63 kHz
1 1 0 0 fCLK/2
12
488 Hz 1.22 kHz 2.44 kHz 4.88 kHz 7.81 kHz
1 1 0 1 fCLK/2
13
244 Hz 610 Hz 1.22 kHz 2.44 kHz 3.91 kHz
1 1 1 0 fCLK/2
14
122 Hz 305 Hz 610 Hz 1.22 kHz 1.95 kHz
1 1 1 1 fCLK/2
15
61 Hz 153 Hz 305 Hz 610 Hz 976 Hz
Note When changing the clock selected for fCLK (by changing the system clock control register (CKC)
value), stop timer array unit (TTm = 00FFH).
The timer array unit must also be stopped if the operating clock (f
MCK) specified by using the
CKSmn0 and CKSmn1 bits or the valid edge of the signal input from the TImn pin is selected as the
count clock (f
TCLK).
Caution Be sure to clear bits 15, 14, 11, 10 to “0”.
Remarks 1. f
CLK: CPU/peripheral hardware clock frequency
2. The above f
CLK/2
m
is not a signal which is simply divided fCLK by 2
m
, but a signal which becomes high
level for one period of f
CLK from its rising edge (m = 1 to 15). For details, see 6.5.1 Count clock
(f
TCLK).
