RL78/G13 CHAPTER 7 REAL-TIME CLOCK
R01UH0146EJ0100 Rev.1.00 447
Sep 22, 2011
Here is an example of setting the alarm.
Day 12-Hour Display 24-Hour Display Time of Alarm
Sunday
W
W
0
Monday
W
W
1
Tuesday
W
W
2
Wednesday
W
W
3
Thursday
W
W
4
Friday
W
W
5
Saturday
W
W
6
Hour
10
Hour
1
Minute
10
Minute
1
Hour
10
Hour
1
Minute
10
Minute
1
Every day, 0:00 a.m. 1 1 1 1 1 1 1 1 2 0 0 0 0 0 0
Every day, 1:30 a.m. 1 1 1 1 1 1 1 0 1 3 0 0 1 3 0
Every day, 11:59 a.m. 1 1 1 1 1 1 1 1 1 5 9 1 1 5 9
Monday through
Friday, 0:00 p.m.
0 1 1 1 1 1 0 3 2 0 0 1 2 0 0
Sunday, 1:30 p.m. 1 0 0 0 0 0 0 2 1 3 0 1 3 3 0
Monday, Wednesday,
Friday, 11:59 p.m.
0 1 0 1 0 1 0 3 1 5 9 2 3 5 9
