RL78/G13 CHAPTER 11 A/D CONVERTER
R01UH0146EJ0100 Rev.1.00 494
Sep 22, 2011
Figure 11-7. Format of A/D Converter Mode Register 2 (ADM2) (2/2)
Address: F0010H After reset: 00H R/W
Symbol 7 6 5 4 <3> <2> 1 <0>
ADM2 ADREFP1 ADREFP0 ADREFM 0 ADRCK AWC 0 ADTYP
AWC Specification of the SNOOZE mode
0 Do not use the SNOOZE mode function.
1 Use the SNOOZE mode function.
When there is a hardware trigger signal in the STOP mode, the STOP mode is exited, and A/D conversion is performed
without operating the CPU (the SNOOZE mode).
• The SNOOZE mode function can only be specified when the high-speed on-chip oscillator clock is selected for the
CPU/peripheral hardware clock (f
CLK). If any other clock is selected, specifying this mode is prohibited.
• Using the SNOOZE mode function in the software trigger mode or hardware trigger no-wait mode is prohibited.
• Using the SNOOZE mode function in the sequential conversion mode is prohibited.
• When using the SNOOZE mode function, specify a hardware trigger interval of at least “A/D conversion time with
stabilization wait time” listed for Table 11-3.
ADTYP Selection of the A/D conversion resolution
0 10-bit resolution
1 8-bit resolution
Caution Only rewrite the value of the ADM2 register while conversion operation is stopped (which is
indicated by the ADCS bit of A/D converter mode register 0 (ADM0) being 0).
Figure 11-8. ADRCK Bit Interrupt Signal Generation Range
1111111111
0000000000
ADCR register value
(A/D conversion result)
<1>
(ADLL ≤ ADCR ≤ ADUL)
<2>
(ADCR < ADLL)
<3>
(ADUL < ADCR)
ADUL register setting
INTAD is generated
when ADRCK = 0.
INTAD is generated
when ADRCK = 1.
INTAD is generated
when ADRCK = 1.
ADLL register setting
<R>
