RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0146EJ0100 Rev.1.00 535

Sep 22, 2011

• 64-pin products

Unit Channel Used as CSI Used as UART

Used as Simplified I

0 CSI00 IIC00

1 CSI01

UART0

IIC01

2 CSI10 IIC10

3 CSI11

UART1

IIC11

0 CSI20 IIC20 1

1 CSI21

UART2 (supporting LIN-bus)

IIC21

• 80, 100, 128-pin products

Unit Channel Used as CSI Used as UART

Used as Simplified I

0 CSI00 IIC00

1 CSI01

UART0

IIC01

2 CSI10 IIC10

3 CSI11

UART1

IIC11

0 CSI20 IIC20

1 CSI21

UART2 (supporting LIN-bus)

IIC21

2 CSI30 IIC30

3 CSI31

UART3

IIC31

When “UART0” is used for channels 0 and 1 of the unit 0, CSI00 and CSI01 cannot be used, but CSI10, UART1, or

IIC10 can be used.

Caution Most of the following descriptions in this chapter use the units and channels of the 128-pin products

as an example.
