RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 558
Sep 22, 2011
(8) Serial channel start register m (SSm)
The SSm register is a trigger register that is used to enable starting communication/count by each channel.
When 1 is written a bit of this register (SSmn), the corresponding bit (SEmn) of serial channel enable status
register m (SEm) is set to 1 (Operation is enabled). Because the SSmn bit is a trigger bit, it is cleared immediately
when SEmn = 1.
The SSm register can be set by a 16-bit memory manipulation instruction.
The lower 8 bits of the SSm register can be set with an 1-bit or 8-bit memory manipulation instruction with SSmL.
Reset signal generation clears the SSm register to 0000H.
Figure 12-12. Format of Serial Channel Start Register m (SSm)
Address: F0122H, F0123H (SS0) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SS0 0 0 0 0 0 0 0 0 0 0 0 0 SS03 SS02 SS01 SS00
Address: F0162H, F0163H (SS1) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SS1 0 0 0 0 0 0 0 0 0 0 0 0 SS13 SS12 SS11 SS10
SSmn Operation start trigger of channel n
0 No trigger operation
1 Sets the SEmn bit to 1 and enters the communication wait status
Note
.
Note If a communication operation is already under execution, the operation is stopped.
Cautions 1. Be sure to clear bits 15 to 4 of the SS0 register and bits 15 to 4 of the SS1 register to “0”.
2. For the UART reception, set the RXEmn bit of SCRmn register to 1, and then be sure to set
SSmn to 1 after 4 or more f
CLK clocks have elapsed.
Remarks 1. m: Unit number (m = 0, 1), n: Channel number (n = 0 to 3)
2. When the SSm register is read, 0000H is always read.
<R>
