RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT
R01UH0146EJ0100 Rev.1.00 566
Sep 22, 2011
(16) Noise filter enable register 0 (NFEN0)
The NFEN0 register is used to set whether the noise filter can be used for the input signal from the serial data
input pin to each channel.
Disable the noise filter of the pin used for CSI or simplified I
2
C communication, by clearing the corresponding bit of
this register to 0.
Enable the noise filter of the pin used for UART communication, by setting the corresponding bit of this register to
1.
When the noise filter is enabled, CPU/peripheral hardware clock (f
CLK) is synchronized with 2-clock match
detection. When the noise filter is OFF, only synchronization is performed with the CPU/peripheral hardware clock
(f
MCK)
Note
.
The NFEN0 register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears the NFEN0 register to 00H.
Note For details, see 6.5.1 (2) When valid edge of input signal input from the TI0n pin is selected (CCS0n
= 1) and 6.5.2 Start timing of counter.
Figure 12-20. Format of Noise Filter Enable Register 0 (NFEN0)
Address: F0070H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
NFEN0 0 SNFEN30 0 SNFEN20 0 SNFEN10 0 SNFEN00
SNFEN30 Use of noise filter of RXD2 pin (RXD2/SDA20/SI20/P14)
0 Noise filter OFF
1 Noise filter ON
Set SNFEN30 to 1 to use the RXD3 pin.
Clear SNFEN30 to 0 to use the other than RxD3 pin.
SNFEN20 Use of noise filter of RXD2 pin (RXD2/SDA20/SI20/P14)
0 Noise filter OFF
1 Noise filter ON
Set SNFEN20 to 1 to use the RXD2 pin.
Clear SNFEN20 to 0 to use the other than RxD2 pin.
SNFEN10 Use of noise filter of RXD1 pin (RXD1/ANI16/SI10/SDA10/P03)
0 Noise filter OFF
1 Noise filter ON
Set the SNFEN10 bit to 1 to use the RXD1 pin.
Clear the SNFEN10 bit to 0 to use the other than RxD1 pin.
SNFEN00 Use of noise filter of RXD0 pin (RXD0/TOOLRXD/SDA00/SI00/P11)
0 Noise filter OFF
1 Noise filter ON
Set the SNFEN00 bit to 1 to use the RXD0 pin.
Clear the SNFEN00 bit to 0 to use the other than RxD0 pin.
Caution Be sure to clear bits 7, 5, 3, and 1 to “0”.
