Figure 12-23. Format of Port Mode Registers 0, 1, 3 to 5, 7 to 9, and 14 (PM0, PM1, PM3 to PM5, PM7 to PM9,
and 14)
Address: FFF20H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM0 1 PM06 PM05 PM04 PM03 PM02 PM01 PM00
Address: FFF21H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM1 PM17 PM16 PM15 PM14 PM13 PM12 PM11 PM10
Address: FFF23H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM3 1 1 1 1 1 1 PM31 PM30
Address: FFF24H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM4 PM47 PM46 PM45 PM44 PM43 PM42 PM41 PM40
Address: FFF25H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM5 1 1 PM55 PM54 PM53 PM52 PM51 PM50
Address: FFF27H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM7 PM77 PM76 PM75 PM74 PM73 PM72 PM71 PM70
Address: FFF28H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM8 PM87 PM86 PM85 PM84 PM83 PM82 PM81 PM80
Address: FFF29H After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM9 PM97 PM96 PM95 PM94 PM93 PM92 PM91 PM90
Address: FFF2EH After reset: FFH R/W
Symbol 7 6 5 4 3 2 1 0
PM14 PM147 PM146 PM145 PM144 PM143 PM142 PM141 PM140
PMmn Pmn pin I/O mode selection (m = 0, 1, 3 to 5, 7 to 9, 14; n = 0 to 7)
0 Output mode (output buffer on)
1 Input mode (output buffer off)
