(2) Operation procedure
Figure 12-35. Initial Setting Procedure for Master Reception
Figure 12-36. Procedure for Stopping Master Reception
Remark Even after communication is stopped, the pin level is retained. To resume the operation, re-set serial
output register m (SOm) (see Figure 12-37 Procedure for Resuming Master Reception).
Starting setting to stop
Setting the STm register
Stopping communication
Write 1 to the STmn bit of the target
channel.
Stop communication in midway.
Set an operation mode, etc.
Starting initial setting
Setting the PER0 register
Setting the SPSm register
Setting the SMRmn register
Setting the SCRmn register
Setting the SDRmn register
Setting the SOm register
Setting port
Writing to the SSm register
Starting communication
Release the serial array unit from the
reset status and start clock supply.
Set the operation clock.
Set a communication format.
Set the initial output level of the serial
clock
(
CKOmn
)
.
Enable clock output of the target channel
by setting a port register and a port mode
register.
Set dummy data to the SIOp register (bits
7 to 0 of the SDRmn register) and start
communication.
Set the SSmn bit of the target channel to 1
and set the SEmn bit to 1 (to enable
operation).
Set a transfer baud rate (setting the
transfer clock by dividing the operation
clock (f
MCK)).
