RL78/G13 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0146EJ0100 Rev.1.00 656

Sep 22, 2011

(3) Processing flow

Figure 12-89. Timing Chart of UART Reception

SSmn

SEmn

SDRmn

RxDq pin

Shift

INTSRq

TSFmn

ST ST

STmn

Data reception (7-bit length)

Receive data 1

Receive data 2

Receive data 3

Receive data 2

Receive data 1

Shift operation

Receive data 3

Remark m: Unit number (m = 0, 1), n: Channel number (n = 1, 3), mn = 01, 03, 11, 13

r: Channel number (r = n − 1), q: UART number (q = 0 to 3)
