RL78/G13 CHAPTER 2 PIN FUNCTIONS

R01UH0146EJ0100 Rev.1.00 66

Sep 22, 2011

(3/3)

Function Name I/O Function After Reset Alternate Function

P130 Output Output port

−

P137 Input

Port 13.

1-bit output port and 1-bit input port.

Input port INTP0

P140 PCLBUZ0/INTP6

P141 PCLBUZ1/INTP7

P142 SCK30/SCL30

P143 SI30/RxD3/SDA30

P144 SO30/TxD3

P146

Input port

−

P147

I/O

Port 14.

7-bit I/O port.

Input of P142 and P143 can be set to TTL input buffer.

Output of P142 to P144 can be set to N-ch open-drain output

DD tolerance).

P147 can be set to analog input.

Input/output can be specified in 1-bit units.

Use of an on-chip pull-up resistor can be specified by a

software setting.

Analog input

port

ANI18

P150 ANI8

P151 ANI9

P152 ANI10

P153

I/O

Port 15.

4-bit I/O port.

Input/output can be specified in 1-bit units.

Analog input

port

ANI11
