Renesas RTK79210**B00000BE User Manual

RZ/A2M SUB Board RTK79210XXB00000BE 1. Overview
R20UT4398EJ0100 Rev.1.00 1-8
2018.10.11
Table 1.2 - Table 1.3 list the main components mounted on the RTK79210XXB00000BE.
Table 1.2 Main Components on RTK79210XXB00000BE (1) IC
Component
Number
Component Name
Type (Manufacturer)
Recommended Optional
Components
U21
Audio CODEC
WM8978CGEFL/V (Cirrus)
U23
USB serial converter IC
R5F10JBCANA#U0 (Renesas)
U27, U28
Ethernet PHY
RTL8201FL-VB-CG (Realtek)
U30
SDRAM
IS42S16320F-7TL (ISSI)
U31
NAND flash memory
Not used
S34ML01G100TFI000
(Cypress)
U32
EEPROM
R1EX24128ASAS0A (Renesas)
X1
Audio oscillator
SG-8002DC_11.2896MHz_PCB
(EPSON)
11.2896MHz
X3
USB serial converter IC crystal oscillator
CX2520DB12000D0PPSC1
(Kyocera)
12MHz
X4
Ethernet PHY oscillator
KC2016K50.0000C1GE00
(Kyocera)
50MHz
X5
VDC6 oscillator
SG-8002DC_40MHz_PCB
(EPSON)
40MHz
X6
CMOS camera oscillator
Not used
SG-8002DC (EPSON)
Table 1.3 Main Components mounted on RTK79210XXB00000BE (2) Connector
Component
Number
Component Name
Type (Manufacturer)
Recommended Optional
Components
CN1
CPU board connector
(SODIMM 204-pin)
2013297-1 (TE)
CN2
DRP connector
HIF3FC-40PA-2.54DSA (71) (HRS)
CN3
Mic in pin jack
STX-3500-3NTR (Kycon)
CN4
Line out pin jack
STX-3500-3NTR (Kycon)
CN5
Serial port connector
ZX62-B-5PA (33) (HRS)
USB Micro-B
CN8, CN9
LAN connector (RJ-45)
J3011G21DNL (Pulse)
CN10
SD card slot
DM1B-DSF-PEJ (82) (HRS)
CN12
USB serial A receptacle
UBA-R4R-D14-4D (LF) (SN) (JST)
CN13
USB Mini-B receptacle
KMBX-SMT-5S-S-30TR (Kycon)
CN14
LVDS connector
DF14A-20P-1.25H (25) (HRS)
CN15
Digital image input/output signal connector
(50-pin)
SFH11-PBPC-D25-RA-BK
(SULLINS)
CN16
LVDS back light connector
53261-0671 (Molex)
CN17
CMOS camera connector (26-pin)
HIF3FB-26DA-2.54DSA (71) (HRS)
CN18
DC power source jack
KLDX-SMT2-0202-ATR (Kycon)
J1
E1 connector
Not used
WM-6-5P (MAC8)
J2
GND connector
HWP-3P-G (MAC8)
