5.3 Turbo Level
7KHVXFWLRQFKDQQHOV¶HI¿FLHQF\FDQEHLQFUHDVHGWR
an additional turbo level.
In this case the extraction unit runs at its maximum
performance.
7KHVHOHFWHGWXUEROHYHOLVVKRZQZLWKD¿IWKEDU
(39) at the suction level display.
Switch turbo level on:
 Press turbo key (49).
Switch turbo level off:
 Press turbo key (49) again
Ƈ the previously used suction level will automati-
cally be resumed
or

press key (46)
Ƈ Ssuction level four will be set.
it is NOT possible to select the turbo level on a suction tube which has the favorite status (see
section 5.4.5).
5.4 Operation
It is only possible to change from single to multi use mode if all suction channels are closed!
For this reason, close the suction on all suction channels before changing.
5.4.1 Single Use
When in single use, the suction takes place at only suction point.
Select single use:
 Press operation mode key (44) repeatedly until
Ƈ the single mode symbol (51) is shown.
The suction level display will remain dark until a suction channel is opened.
2SHQDVXFWLRQFKDQQHOE\
 Pressing the relevant suction channel key (42).
or
 By switching on one of the electrical appliances connected to the Quattro Control-Box.
Ƈ The letter of the opened suction channel is shown in the display.
It is only possible to change the suction level and select the turbo level on this particular opened suc-
tion channel.
The suction level and also the selected turbo level are automatically saved for each individual
suction channel, and reset when the suction channel is opened.
Fig.
9
39
46 49
A
B
C
D
C
Fig. 1
0
51
4442
