Error Code Cause / Meaning Corrective Action
Err 14 Error made when adjusting the on / off
threshold.
The difference between stand-by power
and operating current is too low.
Cancel the on / off threshold setting using the menu
key (30, Fig. 2) and continue as described in section
5.6.4.
Set the on / off threshold with a higher rpm on the
handpiece.
Operate the suction channel manually.
Err 15 Quattro Control-Box without power. Check the power supply for the Quattro Control-Box
(see section 4.6.1).
Err 16 Vacuum power for cleaning is too low. Make sure the pinch valve in the suction channel is
not blocked and that the membrane in the pinch valve
is not defect.
Make sure the dust drawer is in its correct position.
Err 18 Remote control distribution box not con-
nected.
Distribution box faulty.
Check remote control distribution box connection. cf.
also instructions for 2933 0420, remote control starter
kit.
Send distribution box in for repair.
8. Technical Data
8.1 Silent V4
Nominal mains voltage / Nominal frequency 230 V / 50 Hz
Permissible mains voltage
230 V +/-10 %
50 / 60 Hz
Power consumption *) 7.5 A
Electrical power of suction turbine *) 1400 W
Mains input fuse 2 x 10 A(T)
max. connection pressure 8 bar / 116 psi
min. connection pressure 4.5 bar / 65 psi
/S$DWPD[YROXPHÀRZ 63 dB(A)
Number of suction hoses 4
Vacuum pressure, max. 11 kPa / 1.6 psi
)LQHSDUWLFOH¿OWHU
Filter surface area
FIlterquality
DSSUR[PðLQFK
Class M according to EN 60335-2-69
Fill level dust drawer approx. 12 l
Dimensions (height x width x depth) 750 x 350 x 590 mm /
29.53 x 13.78 x 23.23 inch
Weight (empty) approx. 45 kg
6XFWLRQ¿WWLQJV
Internal
External
38 mm / 1.50 inch
45 mm / 1.77 inch
*) Nominal voltage power / Nominal frequency
**) Sound pressure levels according to EN ISO 11202
