Renishaw TS20 - Stylus fitting instructions

3-5
www.renishaw.com/ts20
Stylus tting instructions
The stylus break stem protects the probe in the event of a collision.
Recover stylus tip from
broken break stem
Fitting stylus tip onto new
break stem
Fitting stylus onto probe
Hexagon key
Stylus tip
Countersunk screw
Broken
break
stem
Spanner
Apply to upper ats
Break
stem
Spanner
Apply to upper ats
Hexagon key torque
2.5Nm (1.85lbf.ft)
Stylus tip
with break
stem
Spanner
Apply to lower ats
torque
1.2Nm (0.88lbf.ft)
Tommy bar
To recover stylus tip from a broken stem,
use spanner on upper ats of stem.
Before tting stylus tip onto
new stem, apply Loctite
®
242 to
thread of countersunk screw. Use
spanner on upper ats of stem.
When tting stylus to probe,
support mounting with tommy
bar and use spanner on lower
ats of stem.
NOTE: Break stem - please quote the part number when ordering a replacement stem.
Application
Break stem
part number
Application
Break stem
part number
Application
Break stem
part number
25 mm (tooling) M-2008-0333 32 mm (tooling) M-2008-0604 40 mm (tooling) M-2008-0605
