Renogy MT-50 - Control Parameters - Voltages; Temperature Compensation and Rated Voltage; Over Voltage Disconnect and Charge Limit; Over Voltage Reconnect and Equalization

10
Temperature fluctuation can affect performance in
the system. Therefore, the purpose of temperature
compensation is to adjust the performance of the
system to keep the system functioning normally.
Choose from 0mV to -9mV
Choose between 12V, 24V or AUTO for rated
battery voltage.
Default parameters for over-voltage disconnect
and charge limit.
Default parameters for over-voltage reconnect
and equalization charge rate.
Default Parameters for Boost and Float Charge
Default parameters for Boost reconnection and
Low voltage reconnect
Default parameters for under voltage reconnect
and under voltage warning
Default parameters for low voltage disconnect and
the discharge limit.
Low Voltage Disconnect
11.1 V
Discharge Limit
10.6 V
Under Voltage Reconnect
12.2 V
Under Voltage Warning
12.0 V
Boost Reconnect
13.2 V
Low Voltage Reconnect
12.6
Boost Charge
14.4 V
Float Charge 13.8 V
Over Voltage Reconnect
15.0 V
Equalization Charge
14.6 V
Over Voltage Disconnect
16.0V
Charge Limit
15.0 V
Temp Comp. Coeff
-3mV/°C/2V
Rated Voltage
Auto
