Renogy ROVER BOOST User Manual

32
Technical Specifications
Model RCC10RVRB
Rated System Voltage
Rated Charge Current
Battery Operating Range
Battery Types
Power Limiting Protection
Max Input Current (short-circuit, Isc)
MPPT Tracking Efficiency
Idle Consumption
MPPT Charge Conversion
Efficiency
Temperature Compensation
Operating Temperature Range
Storage Temperature Range
Rated Max Charge Power
MPPT Voltage Range
Solar Input Voltage
Range (VOC)
Grounding Type
Enclosure Rating
Humidity
Electronic Protections
Terminal Range
Weight
Dimensions
Communication
Terminal Size
36V / 48V, Auto Recognition (Non-Lithium)
10A
30 ~ 65 VDC
AGM, GEL, FLOODED, LFP, USER
35A
Up to 600W/36V; 800W/48V
≥ 99%
≤ 2W
≥ 90%
-3mV / ℃ / 2V (Non-Lithium)
0mV / ℃ / 2V; no compensation (Lithium)
-31°F ~ 149°F / -35℃ ~ + 65℃
-40°F ~ 176°F / -40℃ ~ + 80℃
PV Input Power: 500W/36V; 650W/48V
Charging Power: 450W/36V; 600W/48V
15 ~ 25VDC @ 36V
15 ~ 40VDC @ 48V
15 ~ 25VDC @ 36V
15 ~ 40VDC @ 48V
Common Negative Lug (M3)
IP20
Battery overcharging, Battery over discharge,
Battery reverse polarity protection, PV reverse
polarity, PV Reverse flow, PV Short circuit, PV
Power Limiting,Controller internal over-temperature
protection, Charging over-current protection
0-95% RH
16 ~ 2 AWG
2.65 lbs / 1.2 Kg
RS485 / CAN bus signal
M6x12x1mm
CE, FCC Part 15 Class B, RoHSCertification
8.8 x 7.6 x 2.9 inch / 223.9 x 191.9 x 74.5mm
