6.2 • Connection to a home automation system
External 0-10 V control:
6.3 • Pressure curves
Choose 3 positions in order to achieve the desired airflow.
C 1 2 3 4 5 6 7 8
GND
N L
GND
0-10V OUT
Max 1,5mm²
Max 1,5mm²
L
N
230V ~ 50Hz
0
5
10
15
20
25
30
35
40
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
0 25 50 75 100 125 150 175 200 225 250 275 300 325 350 375 400
∆p (Pa)
2V TNO 3V TNO 4V TNO 5V TNO 6V TNO 6,43V TNO
Extract airflow (m³/h)
Power P [W]
6,43V power TNO6V power TNO5V power TNO4V power TNO3V power TNO2V power TNO
