Retrax EQ - Cabin Module (DS4 TH) and T-Harness Installation; Step 1: Module and T-Harness Setup

18 19

• Tonneau cover assembled and installed.
• 2-pin power harness installed
• Cover module LED is solid RED (Installer-allowed mode).
• Easy Plug-and-Play T-harness connection*
*with loose wires to tap on Parking Lights, Tailgate release, or Ground wire.
• Once connected, the Cabin module should power up as usual:
CABIN MODULE (DS4TH) AND T-HARNESS INSTALLATION
Solid Blue
THEN 
Solid Orange O
