Retrax EQ - Cabin Module (DS4 TH) Operation; Installer-Allowed Mode; Factory Reset Behavior

20 21
Installer-allowed mode: The Cabin module is discoverable (or can be detected) by the Installer APP. Note that both
descriptions below are indications that the Cabin module can be ashed (or re-ashed) using the Installer APP. The Cabin
module’s pre-ashed rmware is “Base Firmware”, Out of the box mode, therefore the LED behavior is the following:
If a Factory reset was done on the Cabin module, the LED behavior is the following:
 that when the Cabin module’s LED is solid orange, this is an indicator that a digital rmware was previously
ashed and the congurations are set back to default and any previous devices are now unpaired.
 Reset until clear BT but not Firmware. Must walk through complete setup.
CABIN MODULE (DS4TH)
Solid Blue
THEN THEN
Solid Orange
x3 seconds
O
Solid Blue
THEN
Solid Orange

• T-harness installed as per Wiring Diagram.
• Cabin module is powered up and LED illuminated sequentially (Blue, then orange x3 sec OR solid orange).
• Cabin module is in Installer-allowed mode.
