3. Fast start
13 User manual RHF-Active
3. Fast start
3.1 What this chapter contains
This chapter describes the basic guidelines for installation and commissioning of RHF-ACTIVE,
which should be observed for fast and easy usage.
3.2 First check when unpacking
Please check the goods during and immediately after receipt on the following characteristics:
1
Please check the packaging for intactness and dryness. If this is not the case,
immediately get in contact with the sender.
2
Please check if the type-code on the packaging matches the ordered product. If this is
not the case, immediately get in contact with the sender.
3
Please check for any kind of moisture inside the packaging and for any kind of
damages at the product. If this is not the case, immediately get in contact with the
sender.
4
Please check if the type code on the packaging matches the data on the name plate. If
this is not the case, immediately get in contact with the sender.
5
Please check if the packaging contains all accessories including manual. If this is not
the case, immediately get in contact with the sender.
3.3 Suitability for the application
Please check if all current transformers and the the adjusted parameters asre suitable for the
application before you start up the RHF-Active for the first time.
3.4 Environment conditions
Please check and consider the following environment conditions before starting the installation:
1
Check for the ambient temperature to be below 40°C. If it is higher, consider the
following derating:
>40°C <45°C = 10% ≥45°C <50°C = 20% ≥50°C <55°C = 30%
≥55°C = 100% (off) Ambient temperature above 40°C will affect the lifetime!
2
Check for the ambient temperature to be above -10°C. If it is lower, a heater must be
installed.
Hint: Ambient temperature means the temperature inside the cabinet with the RHF-
Active.
3.
Check for the installation height to be below 1000m above sea level. If it is higher,
consider derating of 1%/100m. This would mean that a RHF-Active 100A at 2000
a.s.m.l. must be loaded with not more than 90A. Operation above 4000m is not
acceptable.
4
Check for ambient moisture to be below 90%. If the moisture is higher, measures for
reduction of moisture must be taken.
5
Check for no direct sunlight exposition of the RHF-Active and for no dust impact. If
that could happen, countermeasures must be taken.
