5. Installation instructions
25 User manual RHF-Active
5.2.1 Mechanical installation
For safe and undisturbed operation, it is mandatory to follow those instructions for mechanical
installation:
1. Clearance between RHF-Active and other components like chokes, cabinet walls,
drives:
100mm in horizontal (left/right) and 100mm in vertical direction (bottom)
2. Clearance between RHF-Active and other RHF-Active:
10mm in horizontal (left/right) and 100mm in vertical direction (bottom)
3. Min. clearance in vertical direction (top):
RHF-Active 15A : 130mm RHF-Active 35A : 180mm
RHF-Active 55A : 180mm RHF-Active 100/150A : 230mm
4. Use screws with min. diameters
RHF-Active 15A : 6mm RHF-Active 35A : 6mm
RHF-Active 55A : 6mm RHF-Active 100/150A : 8mm
