Rexroth IndraDrive C Electrical Data 6-27
DOK-INDRV*-HCS02.1****-PR02-EN-P
X1, Module Bus
The module bus permits data exchange between the drive controllers.
X1f2.FH7
X1 out X1 in
Fig. 6-27: X1
Type Number of
poles
Type of design
Flat line connector 8 Connector on device
Flat line bushing 8 Bushing on flat line
Fig. 6-28: Design
Graphic Representation
Design
