Rexroth IndraDrive C Identification 4-1
DOK-INDRV*-HCS02.1****-PR02-EN-P
4 Identification
4.1 Device Types
Type Code
Note: The following figure illustrates the basic structure of the type
code. Your sales representative will help with the current
status of available versions.
1. Product
1.1 HCS. . . . . . . . = HCS
2. Line
2.1 1.5 to 11 kW. . . . . . . . = 02
3. Design
3.1 1 . . . . . . . . . . . . . . . . . . . . . . = 1
4. Power supply
4.1 feeded . . . . . . . . . . . . . . . . . . . = E
5. Cooling mode
5.1
Air, internal (through integrated blower)
= W
6. Maximum current
6.1 12 A . . . . . . . . . . . . . . . . . . . . . . . . . = 0012
6.2 28 A . . . . . . . . . . . . . . . . . . . . . . . . . = 0028
6.3 54 A . . . . . . . . . . . . . . . . . . . . . . . . . = 0054
6.4 70 A . . . . . . . . . . . . . . . . . . . . . . . . . = 0070
7. Protection mode
7.1 IP 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = A
8. Mains connecting voltage
8.1 AC 200 to 500V ±10% . . . . . . . . . . . . . . . . . . . . . . . . . = 03
9. Other design
9.1 none. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NNNN
9.2 with integrated 24 V power supply . . . . . . . . . . . . . . . . . . . .= NNNV
10. Standard reference
Standard Title Edition
DIN EN 60529 Degrees of protection provided 2000-09
by enclosures (IP-Code)
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
HCS02 . 1E-W0012 -A- 03-NNNN
Fig. 4-1: Type code (power section)
