X6, Motor Temperature Monitoring and Motor Holding Brake
The drive controller is supplied with 24V for the motor holding brake via
connection X13.
DANGER
High electrical voltage! Danger to life, severe
bodily harm by electric shock!
⇒ Always operate the drive controller with plugged on
connector, because high voltages can occur at the
connector at the end of the cable (coming from
motor)!
Type Number of poles Type of design
Spring power 4 Pins on device
Fig. 6-37: Design
Identification of the individual connections:
Identification Significance
1MotTemp+
2MotTemp-
Monitoring the motor
temperature
3 +24 V
40 V
Motor holding brake
Fig. 6-38: Identification of the individual connections
HCS02.1N-W0012, -W0028, -W0054, -W0070:
Cross section
single-wire
[mm²]
Cross section
multi-wire
[mm²]
Cross section
in AWG
0.14-1.5 0.14-1.5 28-16
Fig. 6-39: Connection cross section
Note: Make sure the voltage supply for the motor holding brake is
sufficient. In this respect observe the lengths and cross
sections of the cables used.
Design
Connection Cross Section
