REXROTH HCS02.1E-W0028-NNNN User Manual

6-42 Electrical Data Rexroth IndraDrive C
DOK-INDRV*-HCS02.1****-PR02-EN-P
XS2, Shield Connection (Motor Cable)
XS2
hcs0028_XS2.fh7
hcs0054_XS2.fh7
XS2
Fig. 6-53: XS2
XS2 is used for mounting the accessory HAS02.1 for shield connection of
the motor cable (See Project Planning Manual "Rexroth IndraDrive Drive
System", DOK-INDRV*-SYSTEM*****-PRxx-EN-P.)
