Capacity Ed7 Capacity Screen Ed7
Name Description - Cooling Stages Default Unit Min Max
Comp_Stg1_Cmd Current Compressor Stage 1 Command Off On
Comp_Stg2_Cmd Current Compressor Stage 2 Command Off On
Comp_Stg3_Cmd Current Compressor Stage 3 Command Off On
Comp_Stg4_Cmd Current Compressor Stage 4 Command Off On
Capacity Ed8 Capacity Screen Ed8 will be displayed if the unit is congured with a Reheat Valve
Name Description - Reheat Valve Demand Control Loop Monitoring Default Unit Min Max
DA_Temp Current Discharge Air Temp Deg F
Setpoint: Current Reheat Discharge Air Temp SP Deg F
PI Output: Current output of the control loop % 0 100
RH_Mod_Cmd Current Reheat Modulation Command in vdc vdc 0 10
Capacity Ed9 Capacity Screen Ed9 will be displayed if the unit is congured with Reheat
Name Description Default Unit Min Max
OADhHLo_SP OADehumHighLockoutSP-SetsOAsetpointusedtodisabledehumidication 110 Deg F 0 110
OADhHLoDiff OA Dehum High Lockout SP Differential - Sets differential used for the OADhHLo_SP 2 Deg F 0 10
OADhLLo_SP OADehumLowLockoutSP-SetsOAsetpointusedtodisabledehumidication 58 Deg F 50 100
OADhLLoDiff OA Dehum Low Lockout SP Differential - Sets differential used for the OADhLLo_SP 2 Deg F 05 10
Capacity Ed10 Capacity Screen Ed10 will be displayed if the unit is congured with Reheat
Name Description Default Unit Min Max
DA_Dh_SP
Discharge Air Temp Dehum SP - Sets the discharge air setpoint used to control the reheat
compressorduringdehumidicationmode
70 Deg F 50 100
CC_DA_SP
Cooling Coil Dehum DA SP - Sets the discharge air setpoint used to control unit primary
coolingwhenindehumidicationMode
52 Deg F 45 80
Capacity Ed11 Capacity Screen Ed11
Name Description - Fixed Capacity Compressor 1 Default Unit Min Max
Run Hours: Accumulated Total Run Hours hrs
Num Starts: Accumulated Total Number of Starts
Reset to Zero? Used to reset accumulators to zero
Capacity Ed12 Capacity Screen Ed12
Name Description - Fixed Capacity Compressor 2 Default Unit Min Max
Run Hours: Accumulated Total Run Hours hrs
Num Starts: Accumulated Total Number of Starts
Reset to Zero? Used to reset accumulators to zero
Capacity Ed13 Capacity Screen Ed13
Name Description - Fixed Capacity Compressor 3 Default Unit Min Max
Run Hours: Accumulated Total Run Hours hrs
Num Starts: Accumulated Total Number of Starts
Reset to Zero? Used to reset accumulators to zero
Capacity Ed14 Capacity Screen Ed14
Name Description - Fixed Capacity Compressor 4 Default Unit Min Max
Run Hours: Accumulated Total Run Hours hrs
Num Starts: Accumulated Total Number of Starts
Reset to Zero? Used to reset accumulators to zero
Capacity Ed15 Capacity Screen Ed15 will be displayed if the unit is congured with a Reheat Compressor
Name Description - Reheat Compressor Default Unit Min Max
Run Hours: Accumulated Total Run Hours hrs
Num Starts: Accumulated Total Number of Starts
Reset to Zero? Used to reset accumulators to zero
