Form CP-MAPSIII-D21, Doc No 303070, Page 32
e Dampers Damper Menu - Applicable screens and content will be displayed depending upon unit conguration
Dampers Ee1 Dampers Screen Ee1
Name Description Default Unit Min Max
Control:
Selected Damper Control Strategy - 100% OA, 0-10Vdc Input, Two Position, Four
Position, Bldg Pressure
UnoccVnt_Ena:
Unoccupied Ventilation Enable - Allows OA during the unoccupied mode for damper
control option Two Position
Off
Dmpr_SP_Occ:
Two Position Damper Occ SP - Sets the value that the unit dampers will be commanded to
when the unit is occupied
100 % 0 100
Dmpr_SP_Unocc:
Two Position Damper Unocc SP - Sets the value that the unit dampers will be commanded
to when the unit is unoccupied For an unoccupied setpoint above zero UnoccVnt_Ena
must be turned on
0 % 0 100
Aux_1_SP: Aux 1 Damper Position SP - Damper position setpoint based on Ext Switches 1 and 2 20 % 0 100
Aux_2_SP: Aux 2 Damper Position SP - Damper position setpoint based on Ext Switches 1 and 2 40 % 0 100
Aux_3_SP: Aux 3 Damper Position SP - Damper position setpoint based on Ext Switches 1 and 2 60 % 0 100
Aux_4_SP: Aux 4 Damper Position SP - Damper position setpoint based on Ext Switches 1 and 2 80 % 0 100
Dampers Ee2 Dampers Screen Ee2 will be displayed if the Dampers are selected for Bldg Pressure Control
Name Description - Dampers Bldg Pressure Control Loop Monitoring Default Unit Min Max
Bldg Pressure Current Building Static Pressure iwc -0.5 0.5
Setpoint: Current Building Static Pressure SP 01 iwc -0.5 0.5
PI Output: Current output of the control loop % 0 100
Damper_Cmd Current Damper Output Command in vdc vdc 0 10
f Exh Fan and ERV Exh Fan and ERV Menu - Applicable screens and content will be displayed depending upon unit conguration
Exh Fan and ERV Ef1 Exh Fan and ERV Screen Ef1 (reserved for future use)
g Information Information Menu
Informatin Eg1 Information Screen Eg1
Name Description Default Unit Min Max
Control Program: Program Option currently loaded into the controller
Ver: Current Software Version (number and date)
Bios: Current Bios Version (number and date)
Boot: Current Boot Version (number and date)
h BMS Cong BMS Cong Menu - Applicable screens and content will be displayed depending upon unit conguration
BMS Cong Eh1 BMS Cong Screen Eh1
Name Description Default Unit Min Max
Protocol: Sets BMS Protocol - BACnet MSTP, BACnet IP/Eth or Lon - Default = BACnet
BMS Cong Eh2 BMS Cong Screen Eh2 will be shown when the BMS Protocol is set to BACnet MSTP or BACnet IP/Eth
Name Description Default Unit Min Max
Termconf PlugIn? Sets the BACnet Plugin command No
BMS Cong Eh4 BMS Cong Screen Eh4 will be shown when the BMS Protocol is set to BACnet MSTP
Name Description Default Unit Min Max
Instance: Sets the Instance 77000
Baudrate: Sets the Baudrate - 9600, 19200, 38400 or 76800 38400
MAC Addr: Sets the Mac Address 0 0 127
MaxMasters: Sets the Max Masters 127 0 127
MaxInfoFrames: Sets the Max Info Frames 20 0 255
BMS Cong Eh5 BMS Cong Screen Eh5 will be shown when the BMS Protocol is set to BACnet IP/Eth
Name Description Default Unit Min Max
Instance: Sets the Instance
STATIC IP: Sets the Static IP Address - [0-255] [0-255] [0-255] [0-255]
Subnet:
Sets the Subnet Address - 000.000.000.00 / 255.000.000.00 / 255.255.000.00 /
255.255.255.00
Gatewy: Sets the Gateway - [0-255] [0-255] [0-255] [0-255]
7.0 Controller Display Menus (cont’d)
