4.2CLEARANCES

Figure2:


ULSA/ULSA EC X Y Z(*) U V
025 400 100 100 100 820
035 400 100 100 100 820
050 400 100 100 100 820
075 500 100 100 100 820
100 500 100 100 100 820


(*)Heaterscanbemountedonsuitablenon‐combustiblesupports.




5.INTERNALLAYOUT

Figure3:




1 Metalmeshburner
2 Zeropressure
regulator
3 Venturi
4 Differential
pressureswitch
5 Burnercontroller
6 Fluegasextraction
fan
7 Inspectionwindow
+ignitor+ionisation
electrode
8 LimitcontrolLC3
9 LimitcontrolLC1
9
8
