12.MAINTENANCE

Attention

Itisrecommendedthatmaintenanceiscarriedoutatleastonceayear.Morefrequentservicing
mayberequireddependentupontheenvironmentalcircumstanceswheretheairheateris
installed.Regularinspectionisnecessary,especiallyindirtyareas,toassesstheservicing
frequency.

Removalofservicepanel
1. Removedoorlockatupperandunderside.
2. Liftthepanelholdingitatthebottom.

Substitutionofcombustionairfan
1. Turnoffthemaingassupply.
2. Settheroomthermostatsothereisnoheatdemand.
3. Waituntiltheaircirculationfanhasstoppedrunning.
4. Checkthattheelectricalsupplyisturnedoff.
5. Removetheservicepanel(see‘removalofservicepanel’).
6. Disconnecttheplugs
fromthecombustionairfan.
7. Removetheboltsbetweenthecombustionairfanandthe(bent)gassupplytube.Removethegasket.
8. Removethefixingscrews(ortheassemblyincaseofaULSA075/100EC)connectingtheairintakerestriction
andthecombustionairfan.
9. The
combustionairfancannowberemoved.
10. Removeallthedustfromthecombustionairfanwithasoftclothorbrush.
11. Checkthatthemotorandtheturbineareundamaged.
12. Replaceallpartsinreverseorder.

SubstitutionofbulbthermostatLC3
1. Waituntiltheaircirculationfanhasstoppedrunning.
2. Beforestarting,ensurethattheelectricalsupplyisturnedoffandlocked.
3. Removetheservicepanel(see‘removalofservicepanel’).
4. RemovethebracketbyusingtheLC3.
5. Disconnecttheelectricalconnectionsonthebulbthermostat.
6.
Removethefixingscrewsconnectingthebulbthermostattotheelectricalwiringpanel.
7. Thewholebulbthermostatisnowlooseandcanberemoved.
8. Replaceallpartsinreverseorder.

SubstitutionofbulbthermostatLC1
1. Removethethermocoupleviatheairoutletsideoftheairheater.
2. FollowtheaboveinstructionsNo6to8forthebulbthermostatLC3.

Cleaning&substitutionofburner
Whencleaningandre‐installingtheburner,itisnecessarytomakeuseofakitspeciallydesignedforULSA/ULSAEC
units.Useonlykitswhichareapprovedbythemanufacturerandwhichareappropriatefo ryourappliance.
Usekitnumber3625192025forunitULSA(EC)type025–
Forallothertypes,usekitnumber3625192035.
Alwaysconsultyourdistributorattheslightestdoubt.







