108 | P a g e S V C 8 2 0 ( P ) P o c k e t M a n u a l
108
Section 6: Gas Control Valve
ALWAYS TURN OFF Power, Water & Gas
*Remove 2 Molex connectors and clear tube on left side of
gas control valve (circled in green).
*Remove gas control valve and rotate to access Molex
connectors on back.
IMPORTANT: During reassembly - make sure ALL 3 gas
control valve gaskets are in place.
Gaskets
Front of gas control valve
