S V C 8 2 0 ( P ) P o c k e t M a n u a l P a g e 117
117
1
*Move control board bracket out of way to access outlet
thermistor (follow instructions in Section 1).
*Locate Outlet thermistor on lower left side of unit (circled in
blue).
*To REPLACE thermistor ONLY: Separate BLACK Molex
(circled in green) – thermistor is attached to female end of
Molex (black wire).
2
*Remove 2 screws
*Remove Outlet thermistor
(O-ring should remain in thermistor well)
Outlet thermistor
Blower Motor
