20 | P a g e S V C 8 2 0 ( P ) P o c k e t M a n u a l
20
Connection
Wire
Color
Normal Value
What are
you
checking?
K
Y1-BK6
DC 90-120 V
0.8KΩ-2.4KΩ
Gas inlet
solenoid
valve OK?
K
W2-BK6
DC 90-120 V
0.8KΩ-2.4KΩ
Solenoid
valve 1 OK?
K
GY3-BK6
DC 90-120 V
0.8KΩ-2.4KΩ
Solenoid
valve 2 OK?
K
R5-BK6
DC 90-120 V
0.8KΩ-2.4KΩ
Solenoid
valve 3 OK?
K
BL4-BK6
DC 90-120 V
0.8KΩ-2.4KΩ
Solenoid
valve 4 OK?
