Ricoh Aficio SP 204SN - Print Area

Print Area
The diagram below shows the area of the paper that the machine can print on.
From the printer driver
CHZ904
2
3
3
1
4
4
1. Print area
2. Feed direction
3. Approx. 4.2 mm (0.2 inches)
4. Approx. 4.2 mm (0.2 inches)
• The print area may vary depending on the paper size and printer driver settings.
• Adjust the print position by specifying [Registration] in [System Settings].
2. Loading Paper
28
