Ricoh Aficio SP 5210DN

Place the tray on a flat surface.
2. If you load paper larger than 8
1
/
2
" × 14 " (Legal) , you should extend the tray as follows:
1. Slide the catches inwards to unlock the tray.
CEC007
2. Slide the tray until it stops.
CEC008
3. Return the catches to their original positions.
CEC009
6. Loading Paper
118
6
