Ricoh Aficio SP 5210DN - Page 121

3. Pinch the clip on the side paper guide and slide it to match the standard size.
CEC010
4. Pinch the end guide and slide it inward to match the standard size.
CEC011
5. Set the paper thickness setting switch on the front side of the paper tray according to the
type of the loaded paper.
When loading paper thicker than 105 g/m
2
(28 lb.), slide the switch to the left.
CEC253
Loading Paper in Trays
119
6
