If you are using the camera for the first time, read this section.
Rear View
1
16
15
17
87
9
10
11
12
13
14
2
2
3
4
5
6
Item Name Refer to
1 Picture Display P.16
2 Strap Eyelet P.12
3 Terminal Cover
P.91, 99, 107, 109
4 Speaker P.62
5 USB Terminal P.99, 107, 109
6 AV Output Terminal P.91
7
N ( Macro)
P.28
8 ADJ./OK Button
(
*
)
P.44
9
F ( Flash)
P.29
10
6 ( Playback) Button
P.32
11 MENU Button P.52, 66, 79, 92
12 Fn (Function) Button P.46
13
t ( Self-timer)/D ( Delete) Button
P.30, 35
14 DISP. Button P.34, 38, 40
15 Power (DC input) Cable Cover —
16 Battery/Card Cover P.22
17 Tripod Screw Hole P.123
(
*
)
Instructions in this manual to "Press the ADJ./OK button !"NF"
indicate that you should press the ADJ./OK button in the up, down, left
or right direction. Instructions to "Press the ADJ./OK button" indicate
that you should press directly down on the button.
