Ricoh CX3 User Manual

21
If you are using the camera for the first time, read this section.
Charging the Rechargeable Battery
The rechargeable battery needs to be charged before use.
1
Insert the battery into the battery charger, making sure that
the and markings on the battery match those on the
battery charger.
• The battery label should face up.
Caution ---------------------------------------------------------------------------------
Be careful not to reverse the and sides.
2
Plug the battery charger into an outlet.
• Use the battery charger (BJ-10) to recharge the battery.
• Charging starts. Charging status is indicated by the charger lamp as
shown in the table below. Once charging has finished, unplug the
battery charger from the power outlet.
Charger Lamp Description
Lit Charging
Off Charging complete
Flashing The battery charger terminal may be soiled or the battery
charger/battery may be faulty. Unplug the battery charger
from the power outlet, and remove the battery.
• The estimated battery charging time is shown below. Depending on
the battery level, the charging time differs.
Rechargeable Battery Charging Time
DB-100 Approx. 180 min. (25 °C)

Ricoh CX3 Specifications

General

Megapixel	10 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	3648 x 2736 pixels
Optical zoom	10.7 x
Focal length range	4.9 - 52.5 mm
Interface	USB 2.0
Digital SLR	No
Camera shutter speed	1/30 - 1/2000 s
Focal length (35mm film equivalent)	28 - 300 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Spot Auto Focus
Auto Mode focusing range (tele)	1.5 - ∞ m
Auto Mode focusing range (wide)	0.3 - ∞ m
Light metering	centre-weighted, spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Manual
Flash modes	Auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.28 - 4 m
Flash range (wide)	0.20 - 4 m
Internal memory	88 MB
Compatible memory cards	SD, SDHC
Maximum memory card size	32 GB
Motion JPEG frame rate	5 fps
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Scene modes	Close-up (macro), Documents, Night, Night landscape, Portrait, Sports, Landscape (scenery)
Photo effects	Black&White
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual
Self-timer delay	2 s
Product color	Violet
Battery type	DB-100
Battery life (CIPA standard)	310 shots
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	29.4 mm
Width	101.5 mm
Height	58.3 mm
Weight	185 g
