2. Connection
This chapter explains how to connect cables.
Connecting Audio/Video Signals
Pay attention to the following notes when you connect cables:
• Please turn off all devices.
• Familiarize yourself with the audio/video ports on the machine and the devices you want to use.
Be aware that incorrect connections may adversely affect picture quality or result in the picture not
being displayed.
• Do not remove cables from the ports by pulling the cable itself. Always grasp and pull the
connectors at the end of the cable.
• Ensure that all cables are fully inserted and firmly seated.
Connecting the VGA Input
1. Connect the VGA Input jack on the display to the VGA output jack on a computer using a
D-Sub (15-pin) cable.
2. Connect the computer’s audio output jack to the Audio Input (VGA/DVI) jack on the
machine using a suitable audio cable.
11
