CIP Training L5160/L5130
Throughput
2. Clutch the handle of the waste ink bottle, and then lift up the bottle.
DWT202
3. Hold the bottom of the waste ink bottle, and then tilt the bottle before removing it.
Remove the waste ink bottle while being careful of the tube inserted into the spout of the bottle.
DWT203
1
2
4. Uncap the new waste ink bottle, and then attach the inner and outer caps of the used waste ink
bottle.
1
2
DWT204
To Next Page
