Ricoh LW426 - When B Is Displayed; When C Is Displayed; When P Is Displayed

When B Is Displayed
CAQ004
Lift both imaging unit
opening levers,
and then open the
imaging unit upward.
Remove the
jammed paper.
Close the imaging unit.
When C Is Displayed
CAQ005
Open the paper
exit cover holding
C1 at the rear with
both hands.
Hold the C2 knob,
and then tilt the top
of the fusing unit
forward.
Remove the
jammed paper.
Close the fusing
unit and paper
exit cover.
If you cannot remove
the jammed paper
or the paper misfeed
display does not
disappear, proceed
to "When B Is
Displayed".
When P Is Displayed
CAQ006
Hold both sides of
the scanner cover
with both hands,
and then open the
scanner cover.
Remove the
jammed paper.
Close the scanner
cover with both
hands gently.
Removing Jammed Paper
