Front and left view
1. ADF
(The illustration shows the ARDF.)
Lower the ADF over originals placed on the exposure glass.
If you load a stack of originals in the ADF, the ADF will automatically feed the originals one by one.
2. Exposure glass
Place originals face down here.
3. Vents
Prevent overheating.
4. Control panel
See page 56 "Guide to the Names and Functions of the Machine's Control Panel (When Using the
Standard Operation Panel)" or page 59 "Guide to the Names and Functions of the Machine's Control Panel
(When Using the Smart Operation Panel)".
5.
Main power switch
To operate the machine, the main power switch must be on. If it is off, open the main power switch's cover and
turn the switch on.
6. Internal tray 1
Copied/printed paper and fax messages are delivered here.
7. Front cover
Open to replace the toner cartridge.
2. Getting Started
34
