Ricoh MP C305SPF - Page 62

Technical Bulletin PAGE: 4/4
Model: GR-C1
Date: 16-Sep-14
No.: RD117048
RECOVERY METHOD
Do the following procedure.
1. Pull out the the paper tray as far as possible.
2. Lift up the machine and push the tray from underneath [A] toward the operator side
(toward the right in the photo).
