Technical Bulletin PAGE: 1/1
Model: GR-C1
Date: 2-Jul-15
No.: RD117055
Subject: FSM correction - SBU Test Mode
Prepared by: Yasutaka Yamada
From: 2nd Tech Service Sect., MFP/P Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety
Other ( )
Tier 2
Service Manual Revision
Please delete the ‘Scanner Test Mode’ section from your FSM, because the GR-C1 is not
equipped with the function to print out the SBU test pattern.
6. Troubleshooting > Scanner Test Mode > SBU Test Mode
