Ricoh MP C305SPF User Manual

HDD Option Type C305 (D656)
D117/D118 2-54 SM
6. Remove the controller box cover [A] (
x 6 )
 The screw [B] is different from other five screws.
7. Attach the connection board with the bracket [C] to the HDD with the bracket [D] (
x 2).
8. Connect the SATA cable [A] and the power cable [B] to the HDD (
x 2).
9. Attach the cable clamp [E] to the HDD bracket and clamp the cables from the HDD.

Ricoh MP C305SPF Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
ADF Capacity	50 sheets
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan, Fax
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Print Speed	30 ppm
Paper Capacity	350 sheets
Paper Size	A4, A5, A6, B5
Fax Transmission Speed	Approximately 3 seconds per page
Operating System Compatibility	Windows, Mac, Linux
