Ricoh MP C305SPF - Page 88

Technical Bulletin PAGE: 5/9
Reissued: 20-Mar-15
Model: GR-C1
Date: 14-Jan-15
No.: RD117051b
In the field
How to isolate the symptom
Check SP7-803-002～005 when this issue occurred.
SP7-803
PM counter display
-002
Page: PCU: K
-003
Page: PCU: C
-004
Page: PCU: M
-005
Page: PCU: Y
If PM counter quantity is less than 400~500, it may be Initial symptom.
If PM counter quantity is 400~500 or more, it may be Symptom that occurred with time.
